Product Summary
The Z84C3006PEC is a counter/timer circuit. It is simplified as the CTC connects directly to both the Z80 CUP and the Z80 SIO with no additional logic. In larger systems, address decoders and buffers may be required. The Z84C3006PEC requires a single +5V power supply and the standard Z80 single-phase system clock. It is offered in 28-pin DIP, 44-pin PLCC, and 44-pin QFP packages.
Parametrics
Z84C3006PEC absolute maximum ratings: (1)voltages on VCC with respect to VSS: -0.3 to 7V; (2)voltages on all inputs with respect to VSS: -0.3 to VCC+0.3V; (3)Storage temperature: -65 to 150℃.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 Z84C3006PEC |
ZiLOG |
Microprocessors (MPU) 6MHz CMOS CTC XT |
Data Sheet |
Negotiable |
|
||||||||||
