Product Summary
The PCL-240K is a T single port transformer module. Talema 10/100Base-T transformer modules contain transmit and receive isolation transformers to maintain consistent wave shape and suppression of common mode noise while providing equipment isolation per IEEE 802.3. High impedance common mode quad chokes for additional EMI suppression have been added on some models as required for FCC and CISPR 22 Class B certification.
Parametrics
PCL-240K absolute maximum ratings: (1)Minimum isolation voltage: 1500Vrms; (2)operating temperature range: -40 to 85℃; (3)storage temperature: -40 to 125℃; (4)standard packing: tape and reel.
Features
PCL-240K features: (1)Low profile (2.16mm max) for PC card and cardbus applications; (2)Consistent and reliable coplanarity; (3)Excellent quality at extremely competitive price due to high volume production; (4)Manufactured in an ISO-9001:2000, TS-16949:2002 and ISO-14001:2004 certified Talema facility; (5)Fully RoHS compliant and meets lead free reflow level J-STD-020C.
Diagrams
