TAS5112A

digital amplifier power stage, 50W, 33.5V, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.00~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
10 ~ 500 :	3.00 / Piece

PartNumber:: TAS5112A

Brand:: Texas Instruments - TI | Pack: SOP | D/C: 09+

Availability:: Supply Ability: 2/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. Jacob's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-01

From Other Seller

Part Number:TAS5112A
US $3.00 - 3.00
Quantity:

piece

Product Summary

The TAS5112A is a digital amplifier power stage. It is designed to drive 6Ω speakers at up to 50W per channel. The device incorporates TI’s PurePath Digital technology and is used with a digital audio PWM processor and a simple passive demodulation filter to deliver high-quality, high-efficiency, true-digital audio amplification. Its applications include DVD Receiver, Home Theatre, Mini/Micro Component Systems, Internet Music Appliance.

Parametrics

TAS5112A absolute maximum ratings: (1)DVDD to DGND: -0.3 to 4.2V; (2)GVDD to GND: 33.5V; (3)PVDD to GND: 33.5V; (4)out to GND: 33.5V; (5)maximum operating junction temperature: -40 to 150℃; (6)storage temperature: -40 to 125℃.

Features

TAS5112A features: (1)50W per Channel (BTL) Into 6Ω (Stereo); (2)95-dB Dynamic Range With TAS5026; (3)Less Than 0.1% THD+N (1 W RMS Into 6Ω); (4)Less Than 0.2% THD+N (50 W RMS into 6Ω); (5)Power Efficiency Typically 90% Into 6Ω Load; (6)Self-Protecting Design (Undervoltage, Overtemperature and Short Conditions) With Error Reporting; (7)Internal Gate Drive Supply Voltage Regulator; (8)EMI Compliant When Used With Recommended System Design.
