Product Summary
The NJM4580E is a dual operational amplifier. Featuring noiseless, higher gain bandwidth, high output current and low distortion ratio, and it is most suitable not only for acoustic electronic parts of audio pre-amp and active filter, but also for the industrial measurement tools. The NJM4580E is also suitable for the head phone amp at higher output current, and further more, it can be applied for the handy type set operational amplifier of general purpose in application of low voltage single supply type which is properly biased of the low voltage source.
Parametrics
NJM4580E absolute maximum ratings: (1)supply voltage: ±18V; (2)input voltage: ±15V; (3)differential input voltage: ±30V; (4)output current: ±50mA; (5)power dissipation: 800mW; (6)operating temperature range: -40 to 85℃; (7)storage temperature range: -40 to 125℃.
Features
NJM4580E features: (1)Operating Voltage: ±2V to ±18V; (2)Low Input Noise Voltage: 0.8µVrms typ. ; (3)Wide Gain Bandwidth Product (15MHz typ.); (4)Low Distortion: 0.0005% typ.; (5)Slew Rate: 5V/µs typ. ; (6)Package Outline; (7)Bipolar Technology.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 NJM4580E |
NJR |
Operational Amplifiers - Op Amps Dual |
Data Sheet |
|
|
||||||||||||
 |
NJM4580E-T1 |
NJR |
Operational Amplifiers - Op Amps Dual |
Data Sheet |
Negotiable |
|
||||||||||||
|
NJM4580E-T2 |
NJR |
Operational Amplifiers - Op Amps Dual |
Data Sheet |
Negotiable |
|
||||||||||||
|
NJM4580E-TE2 |
NJR |
Operational Amplifiers - Op Amps Dual |
Data Sheet |
|
|
||||||||||||
|
NJM4580E-TE1 |
NJR |
Operational Amplifiers - Op Amps Dual |
Data Sheet |
|
|
||||||||||||
|
NJM4580E# |
NJR |
IC OPAMP DUAL NOISELESS 8-EMP |
Data Sheet |
|
|
||||||||||||
