Product Summary

The SID2511B01-AO is an NPT IGBT module.

Parametrics

SID2511B01-AO absolute maximum ratings: (1)VCES: 1200V; (2)IC: 200A; (3)ICRM: 400A; (4)TVj: -40 to 150℃; (5)Visol: 2500V; (6)IF: 260A.

Features

SID2511B01-AO features: (1)VGE: 6.5V; (2)Ices: 0.3mA; (3)rCE: 9.3mΩ; (4)Cies: 13nF; (5)FWD: 2.2V; (6)IRRM: 60A; (7)ms: 5Nm.

Diagrams

SID2511B01-AO block diagram
