Product Summary

The MIP2D2 is a PIN photodiode. Stem types of 2-leads(KMIP2) and 1-lead(KPIM1)are available. The flat window type or a pigtail type also available. It is recommended for optical data communication and power monitoring. Its applications include Optical Data Communications, Optical power monitoring.

Parametrics

MIP2D2 absolute maximum ratings: (1)Reverse voltage: 20V; (2)maximum optical power input: 10mW; (3)forward current: 10mA; (4)operating temperature: -40 to 85℃; (5)storage temperature: -40 to 85℃; (6)soldering temperature: 260℃.

Features

MIP2D2 features: (1)Front illuminated planar PIN-PD; (2)Low capacitance and low dark current; (3)Hermetically sealed package with 1.96mm lens cap; (4)High reliability and environmental endurance and the cap height is less than 3mm; (5)Wide operating wavelength range from 1.1m to 1.6m.

Diagrams

MIP2D2 block diagram
